1. Input: 5V/9V/12V/15V 3A, 20V 5A
2. Output: 17.6V/5.5A(100W max)
3. Charging time: about 65-85min (original 65/100W charger is recommended)
4. Interface: Type-C
5. Net weight: about 135g
6. Size: about 18 x 5.5 x 3cm
Features:
1. LCD screen to check battery level
2. Up to 3 batteries can be put in, charging in order of power from high to low, the battery with high power is charged first (not at the same time)
3. Two modes: charging mode (to fully charge the battery), storage mode (to charge the battery below 60% to 60% for long-term storage)
4. Storage Mode: Long press the button for 2 seconds in charging mode to switch to storage mode, the best power for long term storage of drone electric is 60%, storage mode can charge the battery with power lower than 60% to 60% and then stop automatically. Done is displayed after the end of storage (only batteries with less than 60% power can be stored and charged, and the storage function can not be used when the power is greater than 60%)
5. Supports PD fast charging with overcharge/overheat/short-circuit/over-voltage protection
Specification:
General |
Compatible with |
DJI: Mavic 3
|
|
Package Weight |
One Package Weight |
0.16kgs / 0.36lb |
One Package Size |
20cm * 8cm * 6cm / 7.87inch * 3.15inch * 2.36inch |
Carton Weight |
17.00kgs / 37.48lb |
Carton Size |
45cm * 38cm * 34cm / 17.72inch * 14.96inch * 13.39inch |
Loading Container |
20GP: 458 cartons * 100 pcs = 45800 pcs 40HQ: 1064 cartons * 100 pcs = 106400 pcs
|
|
